Product Description
Orion D17 is a GPS / GLONASS / Galileo Beidou / QZSS receiver that provides position / velocity / time output for up to 11G acceleration, 1.5m/sec^3 jerk high dynamics application.
FEATURES
* GPS / GLONASS / Galileo / Beidou / QZSS All-In-View Tracking
* 10 Hz update rate
* Maximum velocity 10Km/sec+
* Position accuracy < 30m 3D-RMS (note 1)
* Velocity accuracy < 1m/sec 3D-RMS (note 1)
* Cold start TTFF under open sky 45sec average (note 2)
* Dimensions 17mm x 22mm x 3mm
note 1: at 8Km/sec velocity, 11G acceleration, 1.5m/sec^3 jerk
note 2: 40dB-Hz or higher signal, at 8Km/sec velocity, 2G acceleration, 1.5m/sec^3 jerk
DOWNLOADS
Datasheet (.pdf, ver 1, 20240911)
