Product Description
NS-HP-GN2 is PX1122R L1/L2/E5b GPS / GLONASS / Galileo / Beidou / QZSS RTK receiver for centimeter level accuracy applications in easy to use breakout board form.
KEY FEATURES
* 230 Channel Carrier Phase Measurement RTK Receiver
* Hardware Supporting:
GPS L1 / L2C
Galileo E1 / E5b
Beidou B1I / B2I
GLONASS L1 / L2
QZSS L1 / L2C
* Integrated RTK, no 3rd party software needed
* 1cm + 1ppm RTK accuracy in seconds
* Fast and reliable performance
* Up to 10Hz concurrent quad-GNSS RTK update rate
* Base or rover mode configurable
* Precise RTK position and heading using two modules
* Heading accuracy 0.27 / 0.07 deg @ 50 / 200 cm baseline
* Output dual-frequency carrier phase measurement in base mode
RTK APPLICATIONS
* Centimeter-level high precision navigation
* Precision agriculture
* Machine control guidance
* Survey and GIS data collection
* Structure and deformation monitoring
RTK applications require a base and a rover. The base can be 3rd party RTK base station service, or one can easily setup a local RTK base to use in base & rover pair operation using two PX1122R.
PPP APPLICATIONS
By submitting dual-frequency RINEX log file, converted from carrier phase raw measurement log file of a single NS-HP-GN2, to online PPP service (OPUS、AUSPOS、CSR-PPP、APPS、GAPS...etc.) one can get absolute accuracy centimeter-precise position result anywhere on Earth without the need of RTK base.
55Km Baseline RTK Initialization Testing
DOWNLOADS
NS-HP-GN2 User Guide (.pdf, ver 0.9, 20220620)
PX1122R Datasheet (.pdf, ver 15, 20210125)
Raw Measurement Protocol (.pdf, ver 1.4.38, 20200417)
Raw Measurement to RINEX Converter (20201125)
GNSS Viewer and Binary Command Interface can be downloaded from RESOURCE page
FIRMWARE UPDATE (must only use following GNSS Viewer 2.1.0xx to update)
PX1122R (20230830)
GNSS Viewer (2.1.125, 20220504)
