PX100-0S-01B GPS Chipset (250pcs)

250 piece pack.

The PX100-0S-01B is a high performance GPS / QZSS /SBAS receiver chipset.

For GPS/GLONASS/Galileo/Beidou/QZSS chipset, check out PX100-0S-01A

GNSS CHIPSET SPEC
* 230 channel Phoenix engine
* Supports GPS, , QZSS, SBAS signal
* 1 ~ 25 Hz update rate
* Position accuracy 1.5m CEP
* Velocity accuracy 0.1m/sec
* Cold start TTFF under open sky 29sec average
* Cold start sensitivity -148dBm
* Tracking sensitivity -165dBm
* Operating range : (altitude < 80km) and (speed < 515m/sec)
* Atomic clock synchronized P1PPS time reference with +/-10nsec accuracy

DOWNLOAD
Datasheet (PDF, ver 1, 20191218)
