PX1120R-EVB : PX1120R L1 RTK Evaluation Board

$60.00

Product Description

Evaluation Board for 12mm x 16mm size PX1120R GPS / GLONASS / Galileo / Beidou / QZSS RTK receiver OEM module.

Supports USB, UART, and Bluetooth SPP interface.

The Bluetooth SPP interface allows rover NTRIP client connection to remote non-line-of-sight RTK base via smartphone over Internet, and doing RTK surveying using Apps such as Mapit GIS, Mobile Topographer, Explorer for ArcGIS, Collector for ArcGIS, FieldGenius for Android, Locus GIS, …etc.

KEY FEATURES
* 230 Channel Carrier Phase Measurement RTK Receiver
* Hardware Supporting:
  GPS     L1
  Galileo E1
  Beidou  B1I
  GLONASS L1
  QZSS    L1
* integrated RTK, no 3rd party software needed
* 1cm + 1ppm RTK accuracy in seconds
* Up to 10Hz quad-GNSS RTK update rate
* Base or rover mode configurable
* Moving base RTK mode for precision heading using two modules
* Simultaneous RTK positioning and RTK heading using two modules
* Output dual-frequency carrier phase measurement in base mode

RTK APPLICATIONS
* Centimeter-level high precision navigation
* Survey and GIS data collection

RTK applications require a base and a rover. The base can be 3rd party RTK base station service, or one can easily setup a local RTK base to use in base & rover pair operation using two PX1120R Evaluation Board.



DOWNLOADS
Getting Started Guide (.pdf, 20220605)
Raw Measurement to RINEX Converter (20201125)

FIRMWARE UPDATE (must only use following GNSS Viewer 2.1.0xx to update)
PX1120R (20230830)
GNSS Viewer (2.1.125, 20220504)

OTHER ITEMS OF INTEREST
Survey Grade Antenna
High Precision Antenna
