PX1125T L1/L5 GNSS Timing

5nsec (1-sigma) accuracy, 12mm x 16mm size, L1/L5 GNSS precision timing receiver module with sub-meter position accuracy.

KEY FEATURES
* 230 channel Phoenix engine
* Hardware Supporting:
  GPS     L1  / L5
  Galileo E1  / E5a
  Beidou  B1I / B2a
  QZSS    L1  / L5
  SBAS    L1
* 5nsec (1‐sigma) timing accuracy
* Position hold mode for GNSS timing operation
* 1PPS generation with 1 satellite in view
* 2nd programmable time pulse phase-locked to 1PPS
1Hz ~ 19.2MHz programmable (10MHz default with ~0.01ppb accuracy while GPS in good 3D fix)
Cold start TTFF under open sky 29sec average
* Sub-meter CEP position accuracy
* Velocity accuracy 0.1m/sec
* Cold start sensitivity -147dBm
* Tracking sensitivity -162dBm
* 1 / 2 / 4 / 5 / 8 / 10 Hz update rate
* Operating range : (altitude < 80km) and (speed < 515m/sec)

APPLICATIONS
* GPS Disciplined Oscillator
* Time Synchronization
* Precise Frequency Generation
